Indicates Process Filter Status, In-Line or Bottom Connect Mounting
Process Filter Gage is designed to determine the state of an inline filter. Determines the pressure drop on either side of a filter.
Features
Simple easy to understand indicator means no guessing filter status
Removable mounting block provides direct mounting options especially in difficult filter access locations
Quick installation reduces time to operation
Product Applications
Filter pressure drop
Filter status
Valve drop
Line loss
Specifications
Service: Liquids/gases compatible with SS, GFN, and fluoropolymer.
Wetted Materials: Aluminum, SS, glass filled nylon, and fluoropolymer.
Accuracy: ±5% F.S.
Temperature Limit: 200°F (93°C).
Pressure Limit: 300 psig (20.7 bar).
Materials: Body: Glass filled nylon; Mounting Block: Aluminum; Lens: Polyester; Elastomers: Fluoroelastomer.
Process Connection: 1/8" female NPT.
Mounting Orientation: Any orientation with 10-32 threaded holes 3/4" apart.
Weight: 9.6 oz (272.2 g).
