Bộ chuyển đổi USB sang RS-485/422 UT-820E
Mã: UT-820E
Giá: Liên Hệ
Hãng sản xuất: UTEK
Feature
1. USB2.0;compliable USB1.1, 1.0
2. Universal interface for RS-422/485 in DB9 PIN; RJ-45 connector
3. Enhanced protection: photoelectric isolation:2.5KVrms /500VDC, 1500W lightning strike protection, ±15KV ESD protection and surging protection and grounding interference protection for each RS-422/485 line.
4. Dedicated DC/DC module,
5. Design of automatic data (TXD) stream control and zero delay.
6. Baud rate: 300-115.2KBPS.
7. Remote wake-up and power supply management supported.
8. USB line powered.
9. Dimensions: 97mm x 64mm x26mm.
10. Working environment: -40℃ to 85℃, relative humidity 5% to 95%.
