Cảm biến dòng chảy V8_WP2

LINK: https://shop.vietphat.com/products/cam-bien-dong-chay-v8-wp2

• Service: Compatible gases or liquids.
• Wetted Materials: Vane and Body: Polyphenylene Sulfide (PPS); Pin and spring: 316 SS or Inconel®; Magnet: Ceramic 8.
• Temperature Limit: 212°F (100°C).
• Pressure Limit: 150 psig (10 bar).
• Enclosure Rating: General purpose; WP/WP2 option is weatherproof.
• Switch Type: SPDT snap switch; MV option: SPDT gold contact snap switch.
• Electrical Rating: 5 A @ 125/250 VAC, 5 A resistive, 3 A inductive @ 30 VDC. MV option: 1 A @ 125 VAC, 1 A resistive, 0.5 A inductive @ 30 VDC.
• Electrical Connections: 18 AWG 18" (460 mm) long.
• Conduit Connection: 1/2" male NPT, 1/2" female NPT on WP and WP2.
• Process Connection: 1" male NPT.
• Mounting Orientation: Actuation/deactuation flow rates are based on horizontal pipe run and are nominal values. Unit cannot be used with vertical down flow.
• Set Point Adjustment: Vane is trimmable.
• Weight: 4.5 oz (0.13 kg).
• Agency Approvals: CE, cURus.
