Technical data
Operation: Distraction of light, (The Tindal effect) microprocessor controlled
Supply voltage: (15-30)VDC
Terminals: For wires with cross section (0.8-2.5)mm2
Degree of protection: IP 43
Operation temperature: Minus 10oC to 55oC
Relative humidity: (93±3) % at 40oC
Sensitivity: In accordance with EN54-7
Mounting: Using base type 7100
Dimensions (base included): Ø100, h 47 mm
Casing material: ABS plastics, white
Weight (base included): 0.100 kg
Protected area: Circle with diameter 15m, h 11m
