| 1. MEASUREMENT | Presure range: | 10 to 1500 psi 0.5 to 100 bar |
| Increment: | 1 psi/0.1 bar | |
| 2. ACCURACY | Accuracy: | ±(0.025% of Reading) |
| Repeatability: | ±0.005% of Reading | |
| Temperature Coefficient: | ±0.00167% of rdg/oC outside of 23oC | |
| 3. WIEGHT MASSES | Pressure Range: | 10 to 1500 psi/50 to 10 000 kPa |
| Gravity: | 9.80655m/s2 (International standard) Local Gravity (Specify) |
|
| Avaiable Units: | psi, kg/cm2, bar, and kPa | |
| 4. PRESSURE SOURCE | Source: | Nitrogen or Instrument / shop air |
| Maximum Supply Pressure: | 1500 psi/100 bar (1000 psi and lower models) 2250 psi/150 bar (models above 1000 psi) |
|
| Minimum Supply Pressure: | 150 psi / 10.3 bar | |
| 5. MATERIAL AND CONNECTION | Weight masses: | Stainless Steel (as standard) |
| Ball: | Ceramic | |
| Connection: | 7/16-20 37o AN4 Male | |
