| 1. ACCURACY | Accuracy: | ±(0.015% of Reading), ±(0.025% of Reading), or ±(0.05% of Reading) |
| Repeatability: | ±0.005% of Reading | |
| Temperature Coefficient: | ±0.00167% of rdg/ oC outside of 23oC | |
| 2. WIEGHT MASSES | Pressure Range: | 0.145 to 30 psi/1 to 200 kPa |
| Gravity: | 9.80655m/s2(International standard) Local Gravity (Specify) |
|
| Avaiable Units: | mbar, bar, psi, inH20, cmH20, g/cm2, mmHg | |
| 3. PRESSURE SOURCE | Source: | Nitrogen or Instrument / shop air |
| Maximum Supply Pressure: | 100 psi / 689 kPa | |
| Minimum Supply Pressure: | 30 psi / 206 kPa | |
| 4. MATERIAL AND CONNECTION | Weight masses: | Stainless Steel (as standard) Aluminum (small incremental weights) |
| Ball: | Ceramic | |
| Connection: | 1/4" Female NPT (with installed adapter to 1/4 tube fitting) | |
