Masses
Operating mass (without ballast)
10800 kg
Max. operating mass (ballasted)
13000 kg
Max. front module mass (ballasted)
6800 kg
Max. rear module mass (ballasted)
6200 kg
Traction
Type
Articulated steering
Turning radius, inside
3550 mm
Turning radius, outside
5650 mm
Vertical oscillation
±9°
Transport speed
0-15 km/h
Working speed
0-10 km/h
Compaction
Static linear load (w/o ballast), front
50 kg/cm
Static linear load (w/o ballast), rear
48 kg/cm
Max. static linear load (ballasted), front
59 kg/cm
Max. static linear load (ballasted), rear
58 kg/cm
Rolling width
2100 mm
Drum overlap
50 mm
Water tank
530 l
Engine
Manufacturer/Model
Deutz TD 3.6 L4 IIIA/T3
Type
Water cooled turbo Diesel
Rated power, ISO 14396
55 kW (74 hp ) @ 2300 rpm
Fuel tank capacity
110 l
