Working width 2010 mm
Cutting depth 320 mm
Cutting drum diameter 1100 mm
Spacing 15 mm
Number of tools 166
Working performance
Operating speed 40 m/min (2.4 km/h)
Travel speed 85 m/min (5 km/h)
4 heavy-duty tracks 1890 x 306 x 685 mm
Tank capacities
Fuel tank 1100 l
Hydraulic tank 270 l
Water tank 3400 l
Loading system
Belt width (collecting convey or) 850 mm
Belt width (discharge conveyor) 800 mm
Theoretical swept volume 470 m3/h
Masses
Transport mass 30.8 t
Operating mass (CE) 33 t
Max. operating mass, fully loaded (CE) 35.5 t
Engine
Manufacturer/Model Cummins QSX 15-C600
Fuel Diesel
Cooling Water
Number of cylinders 6
Rated power, SAE J1995 447 kW (600 hp ) @ 2100 rpm
