Model VP2

Thông số kỹ thuật:

• Service: Dry, clean air.
• Temperature Limits: Process: -20 to 212°F (-29 to 100°C); Ambient: 5 to 125°F (-15 to 51°C).
• Range: Air Velocity: 40 to 5000 fpm (0.2 to 25 m/s); Volumetric Air: 999,999 in selected flow units; Temperature: -20 to 212°F (-29 to 100°C); Relative Humidity: 0 to 100% RH.
• Accuracy:

  • Air Velocity: 0.25 to 10 m/s: ±1.5% of reading ±20 fpm (±0.1 m/s); 10 to 20 m/s: 1.5% of reading ±40 fpm (±0.2 m/s); 20 to 25 m/s: ±1.5% of reading ±60 fpm (±0.3 m/s);

  • Temperature: ±0.54°F @ 77°F (±0.3°C @ 25°C);

  • Relative Humidity: ±2% @ 77°F (25°C) (10 to 90% RH); ±4% (0 to 10% RH and 90 to 100%).

• Response Time: Air Velocity and Air Volume: 1 s; Temperature and Relative Humidity: 1.5 s.
• Probe Length: 8" (203 mm) insertion.
• Battery Charging Limits: 32 to 113°F (0 to 45°C). (Wireless Only).
• Power Requirements: 3.7 V YT562447 Lithium ion battery, installed functional, user replaceable. (Note: Intended to be operated with power cables less than 3 m in length). (Wireless Only).
• Maximum Wireless Distance: 50' (15 m). (Wireless Only).
• Handle Enclosure: Thermoplastic elastomer over polycarbonate.
• Supplied With: Wrist strap.
• Weight: 13.6 oz (385 g).
• Agency Approvals: CE (not while charging), RoHS, FCC compliant.
