Technical Data
Approvals
UL and C-UL Listed
NYC Approved under MEA 177-03-E
Maximum Working Pressure 175 psi (12,1 bar)
Discharge Coefficient K=8.0 GPM/psi½ (115,2 LPM/bar½)
Temperature Rating 155°F (68°C) Sprinkler with 139°F (59°C) Cover Plate
Horizontal Adjustment 1/2 in. (12,7 mm)
