Technical Data
Approvals
UL and C-UL Listed (Refer to the Design Criteria Section)
Polyester coated sprinklers are UL and C-UL Listed as Corrosion Resistant Sprinklers
Maximum Working Pressure 175 psi (12,1 bar)
Discharge Coefficient K= 11.2 GPM/psi½ (161,3 LPM/bar½)
Temperature Rating SW-20: 155°F (68°C) & 200°F (93°C) SW-24: 200°F (93°C)
