UP55A-001-11-00 bộ điều khiển nhiệt độ Yokogawa mới chính hãng
Thông số kĩ thuật : UP55A-001-11-00
Model Suffix Code Description
UP55A
Program Controller (Power supply: 100-240 V AC)
30 program patterns/300 program segments (99 programs patterns/600 program segments when the option /AP is specified. Max. 99 segments per pattern)
(provided with retransmission output or 15 V DC loop power supply, 8 DIs, and 8 DOs)
Type 1: Basic -0
Standard type
Type 2: Functions 0
None
Type 3: Open networks 1
RS-485 communication (Max. 38.4 kbps, 2-wire/4-wire)
Display language(1)
-1
English (Default: Can be switched to other language by the setting.)
Case Color 1
Black (Light charcoal gray)
Fixed code -00 Always "-00"
UP55A-001-11-00
Công ty NATATECH.COM.VN - Chuyên cung cấp các thiết bị và phụ kiện ngành điện, điện tự động hóa như: Mitsubishi, Keyence, Yaskawa,Panasonic, Festo, Norgen ,Omron , Wago và các sản phẩm theo máy.
Để được tư vấn và hỗ trợ liên hệ ngay với em ạ:
• Mr Đạt Nguyễn
• Tel : 0886497585
• Zalo : 0886497585
• Email : natatech006@gmail.com
• Website : Tudonghoacn.com
Chính sách thanh toán :
- Hàng có sẵn : Thanh toán 100%
- Hàng đặt : + Thanh toán 50% khi xác nhận đặt hàng
+ 50% còn lại khi có thông tin giao hàng ( hàng đã về tới công ty )
Hỗ trợ chi phí chuyển phát nhanh , có thể tới kho để nhận hàng trực tiếp , hỗ trợ vận chuyển trong khu vực nội thành một cách nhanh nhất .
Các sản phẩm khác tương tự :
UT52A-000-11-00/DC
UT320-00
UT35A-000-11-00
UT55A-000-11-00/LP
UT55A-000-11-00
UT350-00
UP55A-242-10-00
UP55A-010-11-00
UP55A-000-11-00
UP55A-001-11-00
UP55A-002-11-00
UP55A-011-11-00
UP55A-012-11-00
UP55A-020-11-00
UP55A-021-11-00
UP55A-030-11-00
UP55A-200-10-00
UP55A-022-11-00 Standard Type RS-485 communication Ethernet Dark Gray
UP55A-241-10-00 Heating / cooling type 3 additional aux. analog inputs, 2 Dls & 5 DOs None Light Gray
UP55A-240-10-00 Heating / cooling type 3 additional aux. analog inputs, 2 Dls & 5 DOs None Light Gray
UP55A-230-10-00 Heating / cooling type 10 additional DOs RS-485 Light Gray
UP55A-222-10-00 Heating / cooling type RS-485 communication None Light Gray
UP55A-221-10-00 Heating / cooling type RS-485 communication None Light Gray
UP55A-220-10-00 Heating / cooling type RS-485 communication Ethernet Light Gray
UP55A-212-10-00 Heating / cooling type Remote (1 additional aux. analog) input & 1 additional Dl None Light Gray
UP55A-211-10-00 Heating / cooling type Remote (1 additional aux. analog) input & 1 additional Dl None Light Gray
UP55A-210-10-00 Heating / cooling type Remote (1 additional aux. analog) input & 1 additional Dl RS-485 Light Gray
UP55A-040-11-00 Standard Type 3 additional aux. analog inputs, 2 Dls & 5 DOs None Dark Gray
UP55A-122-11-00 Position proportional type RS-485 communication Ethernet Dark Gray
UP55A-201-10-00 Heating / cooling type None Ethernet Light Gray
UP55A-141-10-00 Position proportional type 3 additional aux. analog inputs, 2 Dls & 5 DOs None Light Gray
UP55A-202-10-00 Heating / cooling type None RS-485 Light Gray
UP55A-241-11-00 Heating / cooling type 3 additional aux. analog inputs, 2 Dls & 5 DOs None Dark Gray
UP55A-242-11-00 Heating / cooling type 3 additional aux. analog inputs, 2 Dls & 5 DOs RS-485 Dark Gray
UP55A-141-11-00 Position proportional type 3 additional aux. analog inputs, 2 Dls & 5 DOs Ethernet Dark Gray
UP55A-240-11-00 Heating / cooling type 3 additional aux. analog inputs, 2 Dls & 5 DOs Ethernet Dark Gray
UP55A-230-11-00 Heating / cooling type 10 additional DOs RS-485 Dark Gray
UP55A-222-11-00 Heating / cooling type RS-485 communication None Dark Gray
UP55A-221-11-00 Heating / cooling type RS-485 communication Ethernet Dark Gray
UP55A-220-11-00 Heating / cooling type RS-485 communication RS-485 Dark Gray
UP55A-202-11-00 Heating / cooling type None None Dark Gray
UP55A-212-11-00 Heating / cooling type Remote (1 additional aux. analog) input & 1 additional Dl RS-485 Dark Gray
UP55A-211-11-00 Heating / cooling type Remote (1 additional aux. analog) input & 1 additional Dl RS-485 Dark Gray
UP55A-210-11-00 Heating / cooling type Remote (1 additional aux. analog) input & 1 additional Dl RS-485 Dark Gray
UP55A-041-11-00 Standard Type 3 additional aux. analog inputs, 2 Dls & 5 DOs None Dark Gray
UP55A-201-11-00 Heating / cooling type None Ethernet Dark Gray
UP55A-120-11-00 Position proportional type RS-485 communication RS-485 Dark Gray
UP55A-142-11-00 Position proportional type 3 additional aux. analog inputs, 2 Dls & 5 DOs None Dark Gray
UP55A-130-11-00 Position proportional type 10 additional DOs RS-485 Dark Gray
UP55A-140-10-00 Position proportional type 3 additional aux. analog inputs, 2 Dls & 5 DOs None Light Gray
UP55A-140-11-00 Position proportional type 3 additional aux. analog inputs, 2 Dls & 5 DOs Ethernet Dark Gray
UP55A-121-11-00 Position proportional type RS-485 communication Ethernet Dark Gray
UP55A-130-10-00 Position proportional type 10 additional DOs RS-485 Light Gray
UP55A-112-11-00 Position proportional type Remote (1 additional aux. analog) input & 1 additional Dl None Dark Gray
UP55A-111-11-00 Position proportional type Remote (1 additional aux. analog) input & 1 additional Dl Ethernet Dark Gray
UP55A-110-11-00 Position proportional type Remote (1 additional aux. analog) input & 1 additional Dl RS-485 Dark Gray
UP55A-100-11-00 Position proportional type None Ethernet Dark Gray
UP55A-101-11-00 Position proportional type None None Dark Gray
UP55A-042-11-00 Standard Type 3 additional aux. analog inputs, 2 Dls & 5 DOs RS-485 Dark Gray
UP55A-102-11-00 Position proportional type None None Dark Gray
UP55A-020-10-00 Standard Type RS-485 communication RS-485 Light Gray
UP55A-102-10-00 Position proportional type None Ethernet Light Gray
UP55A-200-11-00 Heating / cooling type None None Dark Gray
UP55A-021-10-00 Standard Type RS-485 communication None Light Gray
UP55A-022-10-00 Standard Type RS-485 communication Ethernet Light Gray
UP55A-030-10-00 Standard Type 10 additional DOs Ethernet Light Gray
UP55A-040-10-00 Standard Type 3 additional aux. analog inputs, 2 Dls & 5 DOs None Light Gray
UP55A-012-10-00 Standard Type Remote (1 additional aux. analog) input & 1 additional Dl Ethernet Light Gray
UP55A-041-10-00 Standard Type 3 additional aux. analog inputs, 2 Dls & 5 DOs None Light Gray
UP55A-101-10-00 Position proportional type None RS-485 Light Gray
UP55A-110-10-00 Position proportional type Remote (1 additional aux. analog) input & 1 additional Dl None Light Gray
UP55A-111-10-00 Position proportional type Remote (1 additional aux. analog) input & 1 additional Dl Ethernet Light Gray
UP55A-120-10-00 Position proportional type RS-485 communication None Light Gray
UP55A-122-10-00 Position proportional type RS-485 communication RS-485 Light Gray
UP55A-112-10-00 Position proportional type Remote (1 additional aux. analog) input & 1 additional Dl Ethernet Light Gray
UP55A-121-10-00 Position proportional type RS-485 communication Ethernet Light Gray
UP55A-002-10-00 Standard Type None Ethernet Light Gray
UP55A-042-10-00 Standard Type 3 additional aux. analog inputs, 2 Dls & 5 DOs None Light Gray
UP55A-001-10-00 Standard Type None RS-485 Light Gray
UP55A-010-10-00 Standard Type Remote (1 additional aux. analog) input & 1 additional Dl None Light Gray
UP55A-000-10-00 Standard Type None None Light Gray
UP55A-011-10-00 Standard Type Remote (1 additional aux. analog) input & 1 additional Dl None Light Gray
UP55A-100-10-00 Position proportional type None Ethernet Light Gray
UP55A-142-10-00 Position proportional type 3 additional aux. analog inputs, 2 Dls & 5 DOs RS-485 Light Gray
