SAAF Side Access Housings (SAH) has the all-in-one double-walled housing is designed to support SAAF gas-phase cassettes, prefilters, and high-efficiency particulate filters. To prevent by-pass and wasted energy, the patent-pending SAAF Track sealing system locks cassettes and filters in place to form a positive, leak-free seal.
Product Overview
Combines particulate filters, gas-phase cassettes, and high-efficiency filters to create a total clean air solution (removing both airborne particulate and gaseous contaminants)
Patent-pending SAAF™ Seal provides the best seal available and superior filtration efficiency
Wide range of sizes and combinations of filter banks
Available with internal fan
Insulated double-walled construction
Allows for easy installation, operation, and maintenance in a totally self-contained system
Typical Applications
Commercial Buildings
Data Centers
Food and Beverage
Healthcare
Hospitality
Microelectronics
Museums & Historic Storage
Pulp & Paper
Refineries
Schools and Universities
Waste Water Treatment
Specification
Main Structure: Aluminium
Panel Material: Double Wall
Insulation: PU
Pre-Filter Depth (mm): 44 - 46
Secondary Filter: Optional
Media Type: Carbon, Impregnated Carbon, Chemical, Blended
Number of Bed: 1, 2
Bed Depth (mm): 25, 75
Manometer: Included
